Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height

    Buy cheap Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height from wholesalers

    Buy cheap Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height from wholesalers
    • Buy cheap Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height from wholesalers
    • Buy cheap Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height from wholesalers

    Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height

    Ask Lasest Price
    Brand Name : Reliance
    Model Number : DR
    Certification : CE,ISO...
    Price : N/A
    Payment Terms : T/T, L/C
    Supply Ability : Daily capacity up to 15,000 Meters.
    Delivery Time : Ex-work within 1 month on receipt of order.
    • Product Details
    • Company Profile

    Extruded High Copper Radiator Finned Tubes With 10.5mm Fin Height

    Extruded high copper radiator finned tubes with 10.5mm fin height


    Detail:

    General extrusion production capacityGeneral specifications of DR Type-Extruded Fin Tubes

    Extrusion Facility: 14 finning machines.
    Daily capacity up to 15,000 meters.
    Extruded fins type: solid and serrated.

    Tube OD : 50.8mm(2'') max.
    Tube Length : no limit
    Fin Height : 16 mm max.
    Fin Thk : 0.4mm
    Fin Pitch : 1.5mm min.


    Description:
    Manufacturing Process
    A smooth core tube is inserted into an aluminum sleeve and then the fins are extruded out of the aluminum sleeve.

    Fins Type:
    Solid fins & Serrated fins

    Accessories
    Tube Support Box, Clamp or Spacer Box(Materials: Aluminum, Zinc or Stainless Steel).

    Applications:

    The common application fileds are:

    1. Heat exchangers units for power plant(electric, nuclear, thermal and geothermal power plants);
    2. High corrosive systems (condensers, evaporators, sea water desalinations, fertilizing, urea systems, ammonia, gas, corrosive acids);
    3. The petroleum, chemical and petrochemical industries;
    4. The food processing and refrigeration industries;
    5. Natural gas treatment;


    Specifications:

    Extruded Bimetallic Finned Tube is combined with two different materials.

    ItemsGeneral MaterialsPopular ASTM Materials
    Core Tube Material

    Any metallic materials, as carbon steel, low-alloy steel, stainless steel, brass, copper, cooper-nickel alloys, aluminum bronze, nickel alloys etc.
    (Core tube with extremely thin wall materials can be applied.)

    1. Carbon Steel: A179, A192,SA210 Gr A1/C,A106 Gr B
    2. Stainless Steel: TP304/304L,TP316/TP316L/316Ti,
    A789 S31803/S2205 etc...
    3. Copper:UNS12200/UNS14200/UNS70600,
    CuNi70/30,CuNi 90/10
    4. Titanium: B338 Gr 2

    Fins Material

    1. Aluminum
    2. Copper.

    1. Aluminum(Alu.1100,Alu.1060,Alu.6063)
    2. Copper.


    All dimensions are in Inches and specification upon your requests.

    Tube OD

    Fin Height

    Fin Thickness

    Fins per Pitch(Density)

    5/8

    3/8,1/2

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10, 11, 12

    3/4

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10, 11, 12

    1

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10, 11

    1 1/4

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10,

    1 1/2

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10, 11

    1 3/4

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10

    2

    3/8,1/2,5/8

    .015/.016/ .020

    4, 5, 6, 7, 8, 9, 10

    Please email us for more information.


    Extruded High Copper Radiator Finned Tubes With 10.5mm Fin HeightExtruded High Copper Radiator Finned Tubes With 10.5mm Fin Height
