L Type fin tube, core tube material C70600, OD25.4X1.245 with copper fins material C12200

ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock

Quick Detail:

Special order with fastest delivery within 2 weeks for power plant in Saui Arabia in Sep of 2015.

(1) All detailed order specifications as below.

Tube material: ASME B111 C70600
Tube Size :OD 25.4mm X1.245mmWT
Fin material: C12200
Fin O.D. : 57.15mm
Fin thickness: 0.4mm
Fin height: 15.8mm
Fin per inch: 11

Plain ends: 25.4mm+50.8mm

(2) Manufacturing process:

The copper strip is folded into an L SHAPE and wound onto the base tube surface under tension.

The feet of the fins are joined together and cover the finned surface.

(3) Delivery Condition

Tube ends are square cut, free burrs, internally dried and air blown clean.

(4) Packing

The desiccants are put into each package for continental transportation as well.

(5) Applications

An urgent replancement job during the shutdown of power plant.

(6) Other Specifications

About Reliance

Jiangsu Reliance Thermal Equipment Co., Ltd is all about thermal transfer finned tubes products. We have a long-term fabrication and supply experience in the business of FINING MACHINES and FINNED TUBES used in air-cooled heat exchanger, economizers, boilers, gas turbines, refining and petrochemical industries ect.

Advantages

• One-stop manufacturer shop from core tube supply to fin tube machines
• ISO 9001:2015 certified company
• Experienced and dedicated management and qualfied manpower
• Quickest response, competitive price, highese quality and shortest schedule
• Tube stock availability for general grades of carbon steel and stainless steel
• Technical support services for fin tube machines and replacement accessories

FINNED TUBES PRODUCTS & SERVICE AVAILABLE

Fabrication Capacities

(1)  Fourteen extrusion fining lines, daily capacity around 15,000 meters

(2)  Five type L/LL/KL fining lines, daily capacity around 5000 meters

(3)  Seven G- base fining lines, daily capacity around 7000 meters

(4)  Two ERW studding lines, daily capacity around 80000 studs

(5)  Four ERW High Frequency Spiral fining lines, daily capacity around 30 tons

(6)  Three bending machines, maximum capacity 76X4

(7)  Five DC ERW H/HH fining lines, daily capacity around 20 tons

(8)  One PLC high speed punch presser

Reliance have become a qualified manufacturer and reliable supplier for high-quality thermal transfer finned tubes used in air-cooled heat exchanger,economizers,boilers,gas turbines,refining and petrochemical industries ect.

If you are interested in any of our products, please do not hestitate to contact us @reliancemfg@126.com
